TABLE OF CONTENTS
A. Cylindrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
B. Mortise Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
C. Exit Trim Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
D. Installing Outside Lever on Non-Mechanical Override . . . . . . . . . . . . . . . . .36
E. Reversing the Outside Lever for Series Without Mechanical Override . . .36
F. Installing Optional K-I-L Key or Best Removable Core . . . . . . . . . . . . . . . . .37
Override and Outside Lever
G. Testing the Operations of the Outside Lever . . . . . . . . . . . . . . . . . . . . . . . . .39
H. Testing the Mechanical Key Override with Change Key . . . . . . . . . . . . . . . .40
I. Changing Lock Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
J. Changing Best-Type Core . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
K. Removing and Reassembling the Outside Lever . . . . . . . . . . . . . . . . . . . . . .42
L. Installing Rubber Bumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
M. Installing Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
N. Testing the Operation of the Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .center of book
For technical assistance, call 1-800-849-TECH (8324) or 336-725-1331
Please read and follow all directions carefully.
These instructions are designed for use by maintenance professionals or lock
installers who are familiar with common safety practices and competent to per-
form the steps described. Kaba Access Control is not responsible for damage
or malfunction due to incorrect installation.
Important: Carefully inspect windows, doorframe, door, etc. to ensure that the
recommended procedures will not cause damage. Kaba Access Control stan-
dard warranty does not cover damages caused by installation.
2
