A. CYLINDRICAL
CHECKLIST
Parts and Tools List
Each E-Plex 2xxx lockset includes:
• Outside lock housing
• Inside lock assembly
• Outside lever
• Gasket for outside lock housing (not for PowerStar versions)
• Cylindrical latch
• Cylinder drive unit
• Battery holder with 3 AA batteries (not included in PowerStar versions)
• Drilling templates
• Hardware bag, includes:
- Square spindle
- Phillips screw (6-32 x
5
⁄16") (not for PowerStar versions)
- Strike kit
- (3) mounting screws (12-24,
1
⁄8" hex head)
- Allen Key
1
⁄8" — Allen Key
5
⁄64"
- (2) 1" (25 mm) Phillips mounting screws
- (1) extension spring
- (4) pairs of Flat Head screws 10-24
- (3) spacers
• Key Override (Optional)
- (1) cylinder with 2 keys for override (if equipped)
- (1) cylinder plug (if equipped)
- (1) cylinder cap (if equipped)
- (2) adaptors for best-type cylinders (if equipped)
- (1) override shaft tool (if equipped)
Warning: For E-Plex 20xx locks, the Master Code of this lock has been factory
preset: 1,2,3,4,5,6,7,8. To activate lock functions, the master combination must
be changed at the time of installation.
For E-Plex 24xx locks, you will have to generate an access code using the web
application to test the lock operation.
3
