TECHNICAL DESCRIPTION MULTICAL
®
401
5512-091 GB/02.2008/Rev. J1
20
Figure 4: Flow sensor with G5/4 and G2 thread connection
Thread L M H2 A B1 B2
Approx.
weight
kg
G5/4 260 L/2 92.5 17 42 22 2.9
G2 300 L/2 92.5 21 48 31 5.1
Table 3: Weight includes 3 m sensor set. Packing not included.
