TECHNICAL DESCRIPTION MULTICAL
®
401
5512-091 GB/02.2008/Rev. J1
21
Figure 5: Flow sensor with DN25 to DN50 flange connection
Nom. Bolts
Approx.
weight.
diameter L M H2 D H k
Number Thread d
2
kg
DN25 260 L/2 92.5 115 106 85 4 M12 14 5.6
DN40 300 L/2 92.5 150 136 110 4 M16 18 8.9
DN50 270 155 92.5 165 145 125 4 M16 18 10.7
Table 4: Weight includes 3 m sensor set. Packing not included
