TECHNICAL DESCRIPTION ULTRAFLOW
®
54 and 34
5512-385 GB/02.2014/Rev. H1
10
4 Ordering details
4.1 ULTRAFLOW
®
54
q
p
q
i
q
s
Length Meter factor CCC
[m³/h] [m³/h] [m³/h] [mm] [imp/l]
(high res.)
65-5- CAAA -XXX 0.6 0.006 1.2 G¾B (R½) 16 110 300 416 (484) Brass
65-5- CAAD -XXX 0.6 0.006 1.2 G1B (R¾) 16 130 300 416 (484) Brass
(65-5- CAAF -XXX) 0.6 0.006 1.2 G1B (R¾) 16 190 300 416 (484) Brass
(65-5- CDA1 -XXX) 1.5 0.015 3 G1B (R¾) 16 110 100 419 (407) Brass
65-5- CDAA -XXX 1.5 0.015 3 G¾B (R½) 16 110 100 419 (407) Brass
65-5- CDAC -XXX 1.5 0.015 3 G¾B (R½) 16 165 100 419 (407) Brass
65-5- CDAD -XXX 1.5 0.015 3 G1B (R¾) 16 130 100 419 (407) Brass
(65-5- CDAE -XXX) 1.5 0.015 3 G1B (R¾) 16 165 100 419 (407) Brass
65-5- CDAF -XXX 1.5 0.015 3 G1B (R¾) 16 190 100 419 (407) Brass
(65-5- CDCA -XXX) 1.5 0.015 3 DN20 25 190 100 419 (407) Stainless steel
(65-5- CEAD -XXX) 2.5 0.025 5 G1B (R¾) 16 130 60 498 (-) Brass
65-5- CEAF -XXX 2.5 0.025 5 G1B (R¾) 16 190 60 498 (-) Brass
65-5- CECA -XXX 2.5 0.025 5 DN20 25 190 60 498 (-) Stainless steel
65-5- CGAG -XXX 3.5 0.035 7 G5/4B (R1) 16 260 50 451 (436) Brass
65-5- CGCB -XXX 3.5 0.035 7 DN25 25 260 50 451 (436) Stainless steel
65-5- CHAG -XXX 6 0.06 12 G5/4B (R1) 16 260 25 437 (438) Brass
(65-5- CHAH -XXX) 6 0.06 12 G1½B (R5/4) 16 260 25 437 (438) Brass
65-5- CHCB -XXX 6 0.06 12 DN25 25 260 25 437 (438) Stainless steel
65-5- CJAJ -XXX 10 0.1 20 G2B (R1½) 16 300 15 478 (483) Brass
(65-5- CJB2 -XXX) 10 0.1 20 DN40 16 250 15 478 (483) Red brass
65-5- CJCD -XXX 10 0.1 20 DN40 25 300 15 478 (483) Stainless steel
(65-5- CKC4 -XXX) 15 0.15 30 DN50 25 250 10 420 (485) Stainless steel
65-5- CKCE -XXX 15 0.15 30 DN50 25 270 10 420 (485) Stainless steel
65-5- CLCG -XXX 25 0.25 50 DN65 25 300 6 479 (-) Stainless steel
65-5- CMCH -XXX 40 0.4 80 DN80 25 300 5 458 (486) Stainless steel
(65-5- CMCJ -XXX) 40 0.4 80 DN80 25 350 5 458 (486) Stainless steel
65-5- FACL -XXX 60 0.6 120 DN100 25 360 2.5 470 (487) Stainless steel
(65-5- FAD5 -XXX) 60 0.6 120 DN100 16 400 2.5 470 (487) Stainless steel
65-5- FBCL -XXX 100 1 200 DN100 25 360 1.5 480 (488) Stainless steel
65-5-
FBCM
-XXX
100
1
200
DN125
25
350
1.5
480 (488)
Stainless steel
3)
XXX - code for final assembly, approvals etc. - determined by Kamstrup. A few variants may not be available in national approvals.
(…) Country specific variants
Type number
3)
Connection
PN
Material
Table 3. Type numbers of ULTRAFLOW
®
54.
