TECHNICAL DESCRIPTION ULTRAFLOW
®
54 and 34
5512-385 GB/02.2014/Rev. H1
30
7.7.1 Cable length
Maximum allowable cable length between Pulse Transmitter/Pulse Divider and MULTICAL
®
depends on the output
module used in Pulse Transmitter/Pulse Divider as well as how the MULTICAL
®
calculator is connected.
Pulse Transmitter/Pulse
Divider output module 2-wire connection 3-wire connection
Y=2 < 100 m *) < 25 m
Y=3 N/A < 25 m
*) MULTICAL® 601/602 must have sensor connection type D and external 24 VDC supply.
MULTICAL
®
601/602/801
Table 18. Maximum cable length between Pulse Transmitter/
Pulse Divider and MULTICAL
®
.
Please note that using long signal cables requires careful consideration in connection with installation. There
must be a distance of min. 25 cm between signal cables and all other cables to prevent electrical disturbance.
