Kamstrup ULTRAFLOW 54 User Manual

TECHNICAL DESCRIPTION ULTRAFLOW
®
54 and 34
5512-385 GB/02.2014/Rev. H1
13
4.6 Pulse Divider configuration CCC-DD-E-MMM
Pulse Divider is configured for ULTRAFLOW
®
meter factor (CCC) as well as the required meter factor (DD) and pulse
duration (E) for the Pulse Divider according to Table 8 and Table 9.
MMM indicates customer label.
q
p
CCC
[m³/h] [imp/l] [l/imp] Divider DD [ms] [ms] (E=4) [ms] (E=5) [ms] (E=6)
0.6
116
300
3.9
-
-
-
Default
0.6 1 300 33 - 20 50 100
0.6 2.5 750 63 - - - 100
1.5
119
100
3.9
-
-
-
Default
1.5 1 100 33 - 20 50 100
1.5 2.5 250 63 - - - 100
1.5 10 1000 34 - - - 100
2.5
198
60
3.9
- - -
Default
2.5 1 60 33 - 20 50 100
2.5 2.5 150 63 - - - 100
2.5 10 600 34 - - - 100
3.5
151
50
3.9
-
-
-
Default
3.5 1 50 33 - 20 50 -
3.5 2.5 125 63 - - - 100
3.5 10 500 34 - - - 100
3.5 25 1250 64 - - - 100
6
137
25
3.9
- - -
Default
6 1 25 33 - 20 50 -
6 2.5 62.5 63 - - - 100
6 10 250 34 - - - 100
6 25 625 64 - - - 100
10
178
15
3.9
-
-
-
Default
10 1 15 33 - 20 50 -
10 10 150 34 - - - 100
10 25 375 64 - - - 100
15 120 10 3.9
- - -
Default
15 1 10 33 - 20 - -
15 10 100 34 - - 50 100
15 25 250 64 - - - 100
15 100 1000 35 - - - 100
25
179
6
3.9
-
-
-
Default
25 1 6 33 - 20 - -
25 10 60 34 - - 50 100
25 25 150 64 - - - 100
25 100 600 35 - - - 100
Meter factor Pulse duration
Table 8. Configuration options as to meter factor (DD) and pulse duration (E) for
Pulse Divider when connected to ULTRALFOW
®
54 or 34, q
p
0.6…25.
