Kamstrup ULTRAFLOW 54 User Manual

TECHNICAL DESCRIPTION ULTRAFLOW
®
54 and 34
5512-385 GB/02.2014/Rev. H1
9
3 Type overview
Nom. flow q
p
[m³/h]
0.6 G¾Bx110 mm G1Bx130 mm
(G1Bx190 mm)
1.5 G¾Bx110 mm G¾Bx165 mm G1Bx130 mm G1Bx190 mm
(G1Bx110 mm) (G1Bx165 mm) (DN20x190 mm)
2.5 G1Bx190 mm DN20x190 mm
(G1Bx130 mm)
3.5 G5/4Bx260 mm DN25x260 mm
6 G5/4Bx260 mm DN25x260 mm
(G1½Bx260 mm)
10 G2Bx300 mm DN40x300 mm (DN40x250 mm)
15 DN50x270 mm
(DN50x250 mm)
25 DN65x300 mm
40 DN80x300 mm
(DN80x350 mm)
60 DN100x360 mm
(DN100x400 mm)
100 DN100x360 mm DN125x350 mm
(...) Country specific variants
Installation dimensions
Table 2. Type overview.
Thread EN ISO 228-1
Flange EN 1092, PN25. Flange facing type B, raised face
