TECHNICAL DESCRIPTION ULTRAFLOW
®
54 and 34
5512-385 GB/02.2014/Rev. H1
11
4.2 ULTRAFLOW
®
34
q
p
q
i
q
s
Length Meter factor CCC
[m³/h] [m³/h] [m³/h] [mm] [imp/l] (high res.)
65-3- CDAA -XXX 1.5 0.015 3 G¾B (R½) 16 110 100 419 (407) Brass
65-3- CDAD -XXX 1.5 0.015 3 G1B (R¾) 16 130 100 419 (407) Brass
65-3- CEAF -XXX 2.5 0.025 5 G1B (R¾) 16 190 60 498 (-) Brass
65-3-
CGAG
-XXX 3.5 0.035 7 G5/4B (R1) 16 260 50 451 (436) Brass
65-3- CHAG -XXX 6 0.06 12 G5/4B (R1) 16 260 25 437 (438) Brass
65-3- CJAJ -XXX 10 0.1 20 G2B (R1½) 16 300 15 478 (483) Brass
65-3- CJCD -XXX 10 0.1 20 DN40 25 300 15 478 (483) Stainless steel
65-3- CKCE -XXX 15 0.15 30 DN50 25 270 10 420 (485) Stainless steel
65-3- CLCG -XXX 25 0.25 50 DN65 25 300 6 479 (-) Stainless steel
65-3-
CMCH
-XXX 40 0.4 80 DN80 25 300 5 458 (486) Stainless steel
65-3- FACL -XXX 60 0.6 120 DN100 25 360 2.5 470 (487) Stainless steel
65-3- FBCL -XXX 100 1 200 DN100 25 360 1.5 480 (488) Stainless steel
65-3-
FBCM
-XXX
100
1
200
DN125
25
350
1.5
480 (488)
Stainless steel
4)
XXX - code for final assembly, approvals etc. - determined by Kamstrup. A few variants may not be available in national approvals.
Type number
4)
Connection
PN
Material
Table 4. Type numbers of ULTRAFLOW
®
34.
4.3 Accessories for ULTRAFLOW
®
Size
Nipple
Union
Type no.
(2 pcs.)
DN15
R½
G¾
-
6561-323
DN20
R¾
G1
-
6561-324
DN25
R1
G5/4
6561-325
-
DN32
R5/4
G1½
6561-314
-
DN40
R1½
G2
6561-315
-
Glands
Table 5. Glands including gaskets (PN16).
Size (union)
Type no.
Size
Type no.
G¾
2210-061
DN20
2210-147
G1
2210-062
DN25
2210-133
G5/4
2210-063
DN40
2210-132
G1½
2210-064
DN50
2210-099
G2
2210-065
DN65
2210-141
DN80
2210-140
DN100
1150-142
DN125
1150-153
Gaskets for glands
Gaskets for
flange meters PN25
Table 6. Gaskets.
