Assembly Instructions
Assembly Instructions
The assembly requires two people.
When moving this product, make sure to keep it lifted in a horizontal orientation.
Be particularly careful to avoid catching hands and ngers in between parts.
▋ Checking the included parts
Before attempting to assemble this product, ensure that all the parts listed below are included. Please also prepare a Phillips-head
screwdriver.
AA
EE
BB
CC
DD
Main body
Pedal board
(including adjustor bolt)
Screw set Headphone hook set
AC adaptor Power cord
Back board
Side panels (left & right)
Screw (with at washer and spring washer) x 4
Headphone hook Mounting screw (4 x 14 mm) x 2
Tapping screw (long, black) (4 x 30mm) x 4 *
Tapping screw (short, black) (4 x 20mm) x 4 *
Tapping screw (silver) (4 x 16mm) x 4
*
The silver tapping screws are provided in a separate
bag.
* For some of the body colours, silver screws are provided
instead of black screws.
