Appendix
MIDI Implementation
Category Parameter Com. Sub. Part Byte Value (HEX)
6.Control Soft Pedal Adjust 50 12 pp 1 01-0A
Modulation Wheel On/O 54 04 pp 2
Cont.ID=0A (Wheel2<Mod.>) /Value=00~02 (O, On,
Reverse)
Modulation Wheel Assign 54 05 pp 3
Cont.ID=0A (Wheel2<Mod. >) /Func.ID MSB/Func.ID LSB
*<INT>00/00~00/1B, <EXT>00/00~00/78
Modulation Depth Range 55 5D pp 1 00~7F
SW1 On/O 54 04 pp 2 Cont.ID=0B (SW1) /Value=00, 01 (O, On)
SW1 Assign 54 05 7F 3
Cont.ID=0B (SW1) /Func.ID MSB/Func.ID LSB
**00/00~00/09
SW2 On/O 54 04 pp 2 Cont.ID=0C (SW2) /Value=00, 01 (O, On)
SW2 Assign 54 05 7F 3
Cont.ID=0C (SW2) /Func.ID MSB / Func.ID LSB
**00/00~00/09
FSW Pedal On/O 54 04 pp 2 Cont.ID=05 (FSW1) /Value=00, 01 (O, On)
FSW Pedal Assign 54 05
INT/
EXT
3
Cont.ID=05 (FSW1) /Func.ID MSB/Func.ID LSB
*<INT>00/00~00/1B, <EXT>00/00~00/78
EXP Pedal On/O 54 04 pp 2 Cont.ID=07 (EXP1) /Value=00~02 (O, On, Reverse)
EXP Pedal Assign 54 05
INT/
EXT
3
Cont.ID=07 (EXP1) /Func.ID MSB/Func.ID LSB
*<INT>00/00~00/1B, <EXT>00/00~00/78
Right Pedal On/O 54 04 pp 2 Cont.ID=01 (Sub Damper) /Value=00, 01 (O, On)
Right Pedal Assign 54 05
INT/
EXT
3
Cont.ID=01 (Sub Damper) /Func.ID MSB/Func.ID LSB
*<INT>00/00~00/1B, <EXT>00/00~00/78
Center Pedal On/O 54 04 pp 2 Cont.ID=03 (Sostenuto) /Value=00, 01 (O, On)
Center Pedal Assign 54 05
INT/
EXT
3
Cont.ID=03 (Sostenuto) /Func.ID MSB/Func.ID LSB
*<INT>00/00~00/1B, <EXT>00/00~00/78
Left Pedal On/O 54 04 pp 2 Cont.ID=04 (Soft) /Value=00, 01 (O, On)
Left Pedal Assign 54 05
INT/
EXT
3
Cont.ID=04 (Soft) /Func.ID MSB/Func.ID LSB
*<INT>00/00~00/1B, <EXT>00/00~00/78
7.KnobAsgn KnobA Assign (1/2) 54 03 pp 3
Knob ID=00/Para.ID MSB/Para.ID LSB
see 3.6 Assignable Knob Paraemters
KnobB Assign (1/2) 54 03 pp 3
Knob ID=01/Para.ID MSB/Para.ID LSB
see 3.6 Assignable Knob Paraemters
KnobC Assign (1/2) 54 03 pp 3
Knob ID=02/Para.ID MSB/Para.ID LSB
see 3.6 Assignable Knob Paraemters
KnobD Assign (1/2) 54 03 pp 3
Knob ID=03/Para.ID MSB/Para.ID LSB
see 3.6 Assignable Knob Paraemters
KnobA Assign (2/2) 54 03 pp 3
Knob ID=04/Para.ID MSB/Para.ID LSB
see 3.6 Assignable Knob Paraemters
KnobB Assign (2/2) 54 03 pp 3
Knob ID=05/Para.ID MSB/Para.ID LSB
see 3.6 Assignable Knob Paraemters
KnobC Assign (2/2) 54 03 pp 3
Knob ID=06/Para.ID MSB/Para.ID LSB
see 3.6 Assignable Knob Paraemters
KnobD Assign (2/2) 54 03 pp 3
Knob ID=07/Para.ID MSB/Para.ID LSB
see 3.6 Assignable Knob Paraemters
8.VirtTech Voicing 50 01 pp 1
00~0A (Normal, Mellow1, Mellow2, Dynamic, Bright1,
Bright2, Sys.User1 ~5)
User Voicing 50 17 7F 14
User#=00~04/Octave# (n)=00~08/Data (Cn~Bn,
12byte)=3B~40~45 (-5~0~+5)
String Resonance 50 04 pp 1 00, 01~0A (O, 1~10)
Undamped Resonance 50 15 pp 1 00, 01~0A (O, 1~10)
Damper Resonance 50 02 pp 1 00, 01~0A (O, 1~10)
KeyO Eect 50 05 pp 1 00, 01~0A (O, 1~10)
Damper Noise 50 03 pp 1 00, 01~0A (O, 1~10)
Hammer Delay 50 07 pp 1 00, 01~0A (O, 1~10)
Fallback Noise 50 06 pp 1 00, 01~0A (O, 1~10)
3.4 Setup Parameters: EDIT Menu (cont.)
