126
Terminal Description
Value Number(s) Function
64
X2A.12 HL Only the High Leveling speed signal at X2A.12
is active. Drive will not run until enable signal on
X2A.16 and direction signal on X2A.14 or X2A.15
are active.
65
X2A.12,X2A.16 EN,HL Both the Enable and High Leveling speed
signals are active. A direction signal is required to
allow operation.
69
X2A.12, X2A.14,
X2A.16
EN,U,HL Enable, Up and High Leveling speed signals
are active. The drive should run in binary speed
mode.
73
X2A.12, X2A.15,
X2A.16
EN,D,HL Enable, Down and High Leveling speed signals
are active. The drive should run in binary speed
mode.
96
X2A.11, X2A.12 INS Only the Inspection speed signal is active. Drive
will not run until enable signal on X2A.16 and
direction signal on X2A.14 or X2A.15 are active.
97
X2A.11, X2A.12,
X2A.16
EN,INS Both the Enable and Inspection speed signals
are active. A direction signal is required to allow
operation.
101
X2A.11, X2A.12,
X2A,14, X2A.16
EN,U,INS Enable, Up and Inspection speed signals are
active. The drive should run in binary speed
mode.
105
X2A.11, X2A.12,
X2A,15, X2A.16
EN,D,INS Enable, Down and Inspection speed signals
are active. The drive should run in binary speed
mode.
128
X2A.13 H Only the High speed signal is active. Drive will
not run until enable signal on X2A.16 and direc-
tion signal on X2A.14 or X2A.15 are active.
129
X2A.13, X2A.16 EN,H Both the Enable and High speed signals are ac-
tive. A direction signal is required to allow opera-
tion.
133
X2A.13, X2A.14
X2A.16
EN,U,H Enable, Up and High speed signals are active.
The drive should run in binary speed mode.
137
X2A.13, X2A.15
X2A.16
EN,D,H Enable, Down and High speed signals are ac-
tive. The drive should run in binary speed mode.
Diagnostic Parameters
