KEB COMBIVERT F5 User Manual

190
Parentheses designate value in gearless modes
Para. Name E R Res. Lower
Limit
Upper
Limit
Default Unit
LF.2 Signal/Operating Mode E R/W 1 1 6 6: bnspd text
LF.3 Drive con guration E R/W 1 0 6 2: Stop text
LF.4 Drive Mode E R 1 1 4 - text
LF.5 Drive Fault Auto Reset E R/W 1 0 10 5 -
LF.8 Electronic Mtr Protection E R/W 1 0 1 0: OFF text
LF.9 Electronic Mtr Protection Current IM
PM
E R/W 0.1 1 110% Rtd
300% of LF.12
8.0
300% of LF.12
A
A
LF.10 Rated Motor Power IM E R/W 0.1 0.5 125 5 hp
PM R 0.1 0.5 125 5 hp
LF.11 Rated Motor Speed E R/W 0.1 10 6000 1165 rpm
(500.0) (150.0)
LF.12 Rated Motor Current E R/W 0.1 1 110%Rtd 8 A
LF.13 Rated Motor Frequency E R/W 0.1 4 200 60 Hz
(50.0) (50.0)
LF.14 Rated Motor Voltage IM E R/W 1 120 500 230/460 V
Voltage Constant ke PM E 1 1 32000 1 V @ rated rpm
LF.15 Power Factor E R/W 0.01 0.5 1 0.9 -
LF.16 Field Weakening Speed E R/W 0.5 1 6000.0 (500.0) 960.0 (100.0) rpm
LF.17 Rated Motor Torque IM E R lb ft
PM R/W 1 1 10000 18
LF.18 Motor Resistance E R/W 0.001 0 49.999 1.000 ohms
LF.19 Motor Inductance E R/W 0.01 0.01 500 1 mH
LF.20 Contract Speed E R/W 1 0 1600 0 ft/min
LF.21 Traction Sheave Diameter E R/W 0.01 7 80 24 inches
LF.22 Gear Reduction Ratio E R/W 0.01 1 250 30 -
LF.23 Roping Ratio E R/W 1 1 8 1 -
LF.24 Load E R/W 1 0 30000 0 lb
LF.25 Estimated Gear Reduction R 0.01 0 655.35 - -
LF.26 Type of encoder E R/W 1 0 32 - -
LF.27 Encoder Pulse Number E R/W 1 256 16384 1024 ppr
LF.28 Swap Encoder Channels E R/W 1 0 3 0 -
LF.29 Sample rate for encoder E R/W 1 0.5 256 4 mS
LF.30 Control Mode E R/W 1 0 5 IM 0, PM 2 -
A.LF.31 KP Speed E R/W 1 1 50396 3000 -
d.LF.31 KP Speed E R/W 1 1 50396 3000 -
P.LF.31 KP Speed (Synth. Pre-Torque) E R/W 1 1 50396 2000 -
A.LF.32 KI Speed E R/W 1 1 26214 350 -
d.LF.32 KI Speed E R/W 1 1 26214 250 -
P.LF.32 KI Speed (Synth. Pre-Torque) E R/W 1 1 26214 10000 -
A.LF.33 KI Speed Offset E R/W 1 0 8000 3000 -
d.LF.33 KI Speed Offset E R/W 1 0 8000 1000 -
0.LF.36 Maximum Torque E R/W 1 0 23590 1.5 x LF17 lbft
1.LF.36 Maximum Torque E R/W 1 0 23590 1 x LF17 lbft
LF.37 Low Speed Torque Boast E R/W 0.1 0 25.5 5 %
LF.38 Switching Frequency E R/W 1 0 1 0 -
A.1 Parameter List Reference
