KEB COMBIVERT F5 User Manual

125
Terminal Description
Value Number(s) Function
1)
0
none none No signals are active on terminal X2A.10 to
X2A.17
1
X2A.16 EN Only the enable signal is active on X2A.16. Drive
will not run until one of the direction signals on
X2A.14 or X2A.15 are active
2
X2A.17 RST Only the fault reset signal is active on X2A.17
4
X2A.14 U Only the up signal is active on X2A.14. Drive will
not run until enable signal on X2A.16 is active.
5
X2A.16,X2A.14 EN,U Both the enable and up signals are active. This
is normal during operation.
8
X2A.15 D Only the down signal is active on X2.4. Drive will
not run until enable signal on X2.1 is active.
9
X2A.16,X2A.15 EN,D The enable and down signals are active. This is
normal during operation.
16
X2A.10 I1 Only the option input signal at X2A.10 is active.
Drive will not run until enable signal on X2A.16
and direction signal on X2A.14 or X2A.15 are
active.
17
X2A.10,X2A.16 EN,I1 Both the enable and option input signals are
active. A direction signal is required to allow
operation.
21
X2A.10, X2A.14,
X2A.16
EN,U,I1 Enable, up and option input signals are active.
In analog speed mode, the drive should run.
25
X2A.10, X2A.15,
X2A.16
EN,D,I1 Enable, down and option input signals are
active. In analog speed mode, the drive should
run.
32
X2A.11 L Only the Leveling speed signal at X2A.11 is
active. Drive will not run until enable signal on
X2A.16 and direction signal on X2A.14 or X2A.15
are active.
33
X2A.11,X2A.16 EN,L Both the Enable and Leveling speed signals
are active. A direction signal is required to allow
operation.
37
X2A.11, X2A.14,
X2A.16
EN,U,L Enable, Up and Leveling speed signals are
active. The drive should run in binary speed
mode.
41
X2A.11, X2A.15,
X2A.16
EN,D,L Enable, Down and Leveling speed signals are
active. The drive should run in binary speed
mode.
1) Function is described for Binary speed selection (LF.2 = bnSPd). If using digital speed
selection use terminal number and table for LF.2=d SPd on page 82.
Diagnostic Parameters
Terminal X2A
This parameter displays the status of the digital inputs on terminal X2A.
Each input has a speci c value. See the table below for decoding.
X2A Input state
