24
2.2 Technical Data 480V (Size 20 to 26)
Inverter Size
20 22 23 24 26
Recommended Motor Power [hp] 50 75 100 125 175
Housing size
HRUUU
Unit Hardware 2 2 3 2 2 2 3
Input Ratings
Supply voltage [V] 305...528 ±0 (480 V Nominal voltage )
Supply voltage frequency [Hz] 50 / 60 +/- 2
Input phases
33333
Rated input current [A] 72 105 150 189 254
Recommended wire gauge
1)
[awg] 4 1 2/O 3/O 350
Output Ratings
Rated output power [kVA] 52 80 104 125 173
Rated motor power [kW] 37 55 75 90 132
Rated output current [A] 65 96 136 172 231
Peak current (30 seconds)
2)
[A] 135 172 230 225 270 375 450
Over current fault (E.OC) trip level [A] 162 207 276 270 324 450 540
Output voltage [V] 3 x 0…Vsupply
Output frequency [Hz] Generally 0 to 599Hz (limited by control board and carrier frequency)
Rated switching frequency
3)
[kHz] 4 8 8 8 8 4 4
Maximum switching frequency [kHz] 16 16 16 8 8 8 12
Power loss at rated operation
4)
[W] 900 1500 1500 1900 2400 2800 2800
Stall current at 4kHz [A] 83 115 173 165 198 330 330
Stall current at 8kHz [A] 83 115 150 150 180 180 225
Stall current at 16kHz [A] 45 63 98 – – – 125
6)
Braking Circuit
Min. braking resistance[Ohm] 9 7.5 5 4 4.0
Typ. braking resistance[Ohm] 13 9 6 6 4.3
Max. braking current [A] 90 104 160 200 200
Installation Information
Max. shielded motor cable length
5)
[ft] 165 165
Tightening torque for power terminals [in lb] 35 133 133 220
Environmental
Max. heat sink temperature TOH [°C] 90°C / 194°F °C 90°C 90°C 60°C
Storage temperature [°C] -25...70 °C / -13…158°F
Operating temperature
[°C]
-10...45 °C / 14…113°F
Housing design / protection Chassis / IP20 / Pollution Degree 2
Relative humidity max. 95% without condensation
Approvals
Tested in accordance with… EN 61800-3 /UL508C
Standards for emitted interference EN 55011 Class B / EN 55022 Class A
Standards for noise immunity IEC 1000-4-2 / -3 / -4 / -5/ -6
Climatic category 3K3 in accordance with EN 50178
1) The wire gauge is based on the maximum fuse rating, copper wire with a 75°C insulation rating, THHW or equivalent. If circuit protection is selected
based on the actual input current, the wire size could be reduced.
2) This is the peak output current limited by hardware regulation. The software current control reserves 5% for closed loop regulation.
3) This is the maximum carrier frequency the power stage can support. The actual operating carrier frequency is adjusted and limited by the control
card.
4) This is the power dissipation at the rated carrier frequency, rated voltage and rated load. Operation at reduced carrier frequencies or reduced load
will decrease this value.
5) Max motor cable length when using shielded cable, KEB EMI lter, and the installation must conform to EN55011 / EN55022.
Technical Data
