KEB COMBIVERT F5 User Manual

127
X2A Output state
Terminal X2A
This parameter displays the status of the digital outputs on terminal
X2A. Each output has a speci c value. If more than one output is
active, the sum of the value is displayed.
Value table:
Value Output Function
Terminal
1 X2A.18 +24VDC Solidstate out - AS, At speed
2 X2A.19 +24VDC Solidstate out - FLT, Drive fault
4 X2A.24...26 Form C Relay - RDY, Drive Ready
8 X2A.27...29 Form C Relay - DRO, Drive On
Diagnostic Parameters
Operation phase
0 = Zero Speed
1 = Low speed selected or analog deceleration
2 = High speed run selected or analog start & run
3 = PreTorque Ramp down phase (US.18)
4 = PreTorque Ramp up phase (US.17)
5 = No Direction Selected
6 = no meaning
7 = no meaning
Display Speed
