Internal scanning

The Model 2002 can be used with a scanner card (such as the Model 2001-SCAN or 2001-

TCSCAN) installed in the option slot of the instrument. This section provides basic information

for scanning internal channels. If the scanner card is not already installed, refer to the scanner

card instruction manual.

NOTE

For complete information on scanning (internal and external), refer to Section 2 in

the User’s Manual, and the scanner card instruction manuals.

NOTE

The following steps assume that the Model 2002 is set to the BENCH reset default

conditions (see BENCH DEFAULTS).

Channel 1

Channel 5

OUT A

OUT B

Channel 6

Channel 10

2-POLE

4-POLE

Channels 2–4

Channels 7–9

Reference

Output

Channel 1

Channel 5

OUT A

OUT B

Channel 6

Channel 10

2-POLE4-POLE

Channels 2–4

Channels 7–9

Figure 12

Model 2001-SCAN

and Model

2001-TCSCAN

2-22 Measurement Options

Keithley 2002 Getting Started Manual
