SCPI command syntax

Tree structure

SCPI commands are organized in a tree structure, similar to disk directories in computer op-

erating systems. Each subdirectory is called a subsystem. For example, part of the

SENSe1

sub-

system is listed below and shown in Figure 16.

[SENSe[1]]

:DATA?

:FUNCtion "<name>"

:VOLTage

:DC

:RANGE

[:UPPer] <n>

:AUTO <Boolean> | ONCE

:REFerence <n>

:STATe <Boolean>

:ACQuire

Figure 16

Hierarchy of the

example SENSe1

commands

SENSe1

:DATA? :FUNCtion

:VOLTage

:DC

:RANGe :REFerence

[:UPPer]

:AUTO

:STATe :ACQuire
