Keithley 3706A Reference Manual

Series 3700A System Switch/Multimeter Reference Manual Section 11: TSP command reference
3700AS-901-01 Rev. D/June 2018 11-11
bit.clear()
This function clears a bit at a specified index position.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
No
Usage
result = bit.clear(value, index)
result
Result of the bit manipulation
value
Specified number
index
One-based bit position within value to clear (1 to 32)
Details
Any fractional part of value is truncated to make it an integer. The returned result is also an
integer.
The least significant bit of value is at index position 1; the most significant bit is at index
position 32.
Example
testResult = bit.clear(15, 2)
print(testResult)
The binary equivalent of decimal 15 is 1111. If you
clear the bit at index position 2, the returned
decimal value is 13 (binary 1101).
Output:
1.30000e+01
Also see
Bit manipulation and logic operations (on page 9-21)
bit.get() (on page 11-11)
bit.set() (on page 11-13)
bit.test() (on page 11-15)
bit.toggle() (on page 11-15)
bit.get()
This function retrieves the weighted value of a bit at a specified index position.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
No
Usage
result = bit.get(value, index)
result
Result of the bit manipulation
value
Specified number
index
One-based bit position within value to get (1 to 32)

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
