Keithley 3706A Reference Manual

Section 11: TSP command reference Series 3700A System Switch/Multimeter Reference Manual
11-198 3700AS-901-01 Rev. D/June 2018
dmm.math.enable
This attribute enables or disables math operations on measurements for the selected measurement function.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Reset
DMM reset
Recall setup
Create configuration script
Save setup
0 (dmm.OFF)
Usage
value = dmm.math.enable
dmm.math.enable = value
value
The math enable setting:
▪ Disable: dmm.OFF or 0
▪ Enable: dmm.ON or 1
Details
This attribute is not available for "nofunction". If you write this attribute for "nofunction", an
error message is generated.
When this command is set to on, the math operation specified by the math format command is
performed before completing a measurement.
Example
dmm.func = "dcvolts"
dmm.reset("active")
dmm.measurecount = 5
MathBuffer = dmm.makebuffer(100)
MathBuffer.appendmode = 1
dmm.measure(MathBuffer)
dmm.math.format = dmm.MATH_MXB
dmm.math.mxb.mfactor = 1e6
dmm.math.mxb.bfactor = 0
dmm.math.mxb.units = "["
dmm.math.enable = dmm.ON
Configure the DMM for DC volts.
Reset DC volts to the default settings.
Set the measure count to 5.
Create a reading buffer named MathBuffer that can
store 100 readings.
Set the buffer to append readings.
Take 5 readings and store them in MathBuffer with
no math operation.
Enable math operations for mx+b operation, with m
set to 1e6 and b set to 0, with units set to micro.

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
