Keithley 3706A Reference Manual

Series 3700A System Switch/Multimeter Reference Manual Section 11: TSP command reference
3700AS-901-01 Rev. D/June 2018 11-369
slot[slot].rows.matrix
This attribute returns the number of rows in the matrix on the card in the specified slot.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (R)
Yes
Not applicable
Not applicable
Not applicable
Usage
value = slot[slot].rows.matrix
value
Number of rows in the matrix card of the selected slot
slot
Slot number (1 to 6)
Details
This attribute is only available for a slot if the installed card supports matrix channels. If matrix
channels are not available, the return value is nil.
Example
print(slot[4].rows.matrix)
Returns the number of rows in the matrix on
the card in slot 4.
Example output:
1.2000000000e+01
Also see
slot[slot].columns.matrix (on page 11-358)
slot[slot].idn (on page 11-362)
slot[slot].matrix (on page 11-364)
slot[slot].startchannel.*
These attributes indicates whether or not the channel in the specified slot supports a feature and if so, which
channels support the feature.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (R)
Yes
Not applicable
Not applicable
Not applicable
Usage
value = slot[slot].startchannel.amps
value = slot[slot].startchannel.analogoutput
value = slot[slot].startchannel.digitalio
value = slot[slot].startchannel.isolated
value = slot[slot].startchannel.totalizer
value = slot[slot].startchannel.voltage
value
The channel number of the starting channel of the group of channels that
supports the feature
X
Slot number (1 to 6)

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
