Keithley 3706A Reference Manual

Section 11: TSP command reference Series 3700A System Switch/Multimeter Reference Manual
11-366 3700AS-901-01 Rev. D/June 2018
slot[slot].poles.four
This attribute indicates if a four-pole setting is supported for the channels on the card.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (R)
Yes
Not applicable
Not applicable
Not applicable
Usage
fourPole = slot[slot].poles.four
fourPole
The return value
slot
Slot number (1 to 6)
Details
This attribute only exists if a card is installed and if the card supports four-pole settings for the
channels on the card. If not, the value is nil. If supported, the value is 1.
Example
fourPole3 = slot[3].poles.four
print(fourPole3)
Queries if slot 3 supports four-pole settings
for the channels on the card.
Output if card supports four pole:
1.000000000e+00
Output if card does not support four pole:
nil
Also see
slot[slot].poles.one (on page 11-366)
slot[slot].poles.two (on page 11-367)
slot[slot].poles.one
This attribute indicates if a one-pole setting is supported for the channels on the specified card.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (R)
Yes
Not applicable
Not applicable
Not applicable
Usage
onePole = slot[slot].poles.one
onePole
The return value
slot
Slot number (1 to 6)
Details
This attribute only exists if a card is installed and if the card supports one-pole settings for the
channels on the card. If not, the value is nil. If supported, the value is 1.

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
