Keithley 3706A Reference Manual

Section 11: TSP command reference Series 3700A System Switch/Multimeter Reference Manual
11-282 3700AS-901-01 Rev. D/June 2018
Setting this attribute to zero disables automatic trigger generation.
If any events are detected prior to calling lan.trigger[N].connect(), the event is ignored and
the action overrun is set.
Example
lan.trigger[5].stimulus = trigger.timer[1].EVENT_ID
Use timer 1 trigger event as the
source for LAN packet 5 trigger
stimulus.
Also see
lan.trigger[N].assert() (on page 11-273)
lan.trigger[N].clear() (on page 11-273)
lan.trigger[N].connect() (on page 11-274)
lan.trigger[N].overrun (on page 11-278)
lan.trigger[N].wait() (on page 11-282)
lan.trigger[N].wait()
This function waits for an input trigger.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
triggered = lan.trigger[N].wait(timeout)
triggered
Trigger detection indication (true or false)
N
The trigger packet over LAN to wait for (1 to 8)
timeout
Maximum amount of time in seconds to wait for the trigger event
Details
If one or more trigger events have been detected since the last time lan.trigger[N].wait() or
lan.trigger[N].clear() was called, this function returns immediately.
After waiting for a LAN trigger event with this function, the event detector is automatically reset and
rearmed regardless of the number of events detected.
Example
triggered = lan.trigger[5].wait(3)
Wait for a trigger with LAN packet 5 with a timeout of
3 seconds.
Also see
lan.trigger[N].assert() (on page 11-273)
lan.trigger[N].clear() (on page 11-273)
lan.trigger[N].overrun (on page 11-278)
lan.trigger[N].stimulus (on page 11-280)

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
