Keithley 3706A Reference Manual

Section 11: TSP command reference Series 3700A System Switch/Multimeter Reference Manual
11-428 3700AS-901-01 Rev. D/June 2018
Example
print(tsplink.trigger[1].overrun)
If an event was ignored, displays
true; if an event was not ignored,
displays false.
Also see
tsplink.trigger[N].assert() (on page 11-424)
tsplink.trigger[N].clear() (on page 11-425)
tsplink.trigger[N].mode (on page 11-426)
tsplink.trigger[N].release() (on page 11-428)
tsplink.trigger[N].reset() (on page 11-429)
tsplink.trigger[N].stimulus (on page 11-430)
tsplink.trigger[N].wait() (on page 11-431)
tsplink.trigger[N].pulsewidth
This attribute sets the length of time that the trigger line is asserted for output triggers.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Reset
Recall setup
TSP-Link trigger N reset
Create configuration script
Save setup
10e-6 (10 µs)
Usage
width = tsplink.trigger[N].pulsewidth
tsplink.trigger[N].pulsewidth = width
width
The pulse width (in seconds)
N
The trigger line (1 to 3)
Details
Setting the pulse width to 0 (seconds) asserts the trigger indefinitely.
Example
tsplink.trigger[3].pulsewidth = 20e-6
Sets pulse width for trigger line 3 to 20 μs.
Also see
tsplink.trigger[N].release() (on page 11-428)
tsplink.trigger[N].release()
This function releases a latched trigger on the given TSP-Link trigger line.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
tsplink.trigger[N].release()
N
The trigger line (1 to 3)

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
