Keithley 3706A Reference Manual

Series 3700A System Switch/Multimeter Reference Manual Section 11: TSP command reference
3700AS-901-01 Rev. D/June 2018 11-43
6. Send reading.
7. Set voltage, –12 V to +12 V range, generate positive point 2.
8. Send reading.
9. Set current, 0 mA to +20 mA range, generate point 1.
10. Send reading.
11. Set current, 0 mA to +20 mA range, generate point 2.
12. Send reading.
13. Set current, +4 mA to +20 mA range, generate point 1.
14. Send reading.
15. Set current, +4 mA to +20 mA range, generate point 2.
16. Send reading.
For totalizer channels, a calibration sequence includes these steps:
1. Calibrate 0 V totalizer threshold
2. Calibrate 1.5 V totalizer threshold
You must save the calibration after calibrating and before locking. Use
channel.calibration.save() to save the calibration.
All calibration progress is lost if the calibration data is not saved before you lock the channel.
After calibration, the channel must be locked using channel.calibration.lock().
Also see
channel.calibration.lock() (on page 11-40)
channel.calibration.save() (on page 11-41)
channel.calibration.unlock() (on page 11-44)

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
