TOTALIZER channel options include:
• READ: Displays a value from a channel as a number between 0 and 65535. This menu option
does not appear if a range of channels is selected. Related command: channel.read() (on page
11-83).
• WRITE: Writes a value to a channel. Enter the value between 0 and 65535. Related command:
channel.write() (on page 11-105).
• RESET-STATE: Resets the channel state. Related command: channel.resetstatelatch() (on page
11-86).
• RESET: Restores the factory default settings of selected channels or all channels. Related
command: channel.reset() (on page 11-84).
DAC channel options include:
• READ: Displays a value from a channel. This menu option does not appear if a range of channels
is selected. A number is displayed that is dependent on the channel’s selected mode function, as
well as the card model of the selected channel. Related command: channel.read() (on page 11-
83).
• WRITE: Writes a value from a channel. This menu option does not appear if a range of channels
is selected. A number is displayed that is dependent on the channel’s selected mode function, as
well as the card model of the selected channel. Related command: channel.write() (on page 11-
105)
• RESET-STATE: Resets the channel state. Related command: channel.resetstatelatch() (on page
11-86).
• RESET: Restores the factory default settings of selected channels or all channels. Related
command: channel.reset() (on page 11-84).
For more information, see Working with channels (on page 5-13).
PATTERN ACTION menu options
Allows you to configure and change patterns from the front panel.
To open this menu, in pattern view, press PATT.
Options include:
• CREATE: If no patterns have been created, this is the only option that is displayed. Allows you to
create a new pattern.
• OPEN: Opens the channels in the selected channel pattern.
• CLOSE: Closes the channels in the selected channel pattern. These closures are appended to
any channels that are already closed.
• EXCLOSE: Closes the channels in the selected pattern so that the channels associated with the
pattern are exclusively closed. Any previously closed channels are opened.
• EXSLOTCLOSE: Exclusively closes the channels in the specified channel pattern for the
selected slots.
• VIEW: Displays the channels that are in the selected pattern.
• DELETE: Deletes the channel pattern.
• RESET: Displays options that allow you to reset the channels in the selected channel pattern to
factory default settings. Resetting a channel pattern causes that pattern to be deleted because
when channels are reset, they delete patterns that contain them.
For information about working with channel patterns, see Channel patterns (on page 5-19).
