Keithley 3706A Reference Manual

Series 3700A System Switch/Multimeter Reference Manual Section 11: TSP command reference
3700AS-901-01 Rev. D/June 2018 11-371
print(" no totalizer channels")
end
if (slot[SlotNumber].startchannel.analogoutput == nil) and
(slot[SlotNumber].endchannel.analogoutput == nil) then
print(" no analog output channels")
else
print(" Start analog output channel is " ..
slot[SlotNumber].startchannel.analogoutput)
print(" End analog output channel is " ..
slot[SlotNumber].endchannel.analogoutput)
end
if (slot[SlotNumber].matrix == 1) then
print(" Channels on card are matrix type")
end
end
end
for x = 1,6 do
print("Checking card channels in slot " .. x)
CardChannels(x)
end
If the Series 3700A contains the following cards:
▪ Slot 1: 3732
▪ Slot 2: 3720
▪ Slot 3: 3750
▪ Slot 4: Empty
▪ Slot 5: 3721
▪ Slot 6: Empty
The output of this example is similar to:
Checking card channels in slot 1
no voltage channels
no amp channels
no digio channels
no totalizer channels
no analog output channels
Channels on card are matrix type
Checking card channels in slot 2
Start voltage channel is 1
End voltage channel is 60
no amp channels
no digio channels
no totalizer channels
no analog output channels
Checking card channels in slot 3
no voltage channels
no amp channels
Start digital i/o channel is 1
End digital i/o channel is 5
Start totalizer channel is 6
End totalizer channel is 9
Start analog output channel is 10
End analog output channel is 11
Checking card channels in slot 4
Slot is Empty
Checking card channels in slot 5

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
