Keithley 3706A Reference Manual

Appendix A: LAN concepts and settings Series 3700A System Switch/Multimeter Reference Manual
A-6 3700AS-901-01 Rev. D/June 2018
7. Double-click Internet Protocol Version 4 (TCP/IPv4) in the items list. The Internet Protocol
Version 4 (TCP/IPv4) Properties dialog box is displayed.
Figure 149: Internet Protocol (TCP/IP) Properties dialog box
8. Select Use the following IP address. The option for "Use the following DNS server addresses"
is automatically selected.
9. Set the IP address. If the IP address and subnet mask fields:
▪ Contain values: Record the IP address, subnet mask, default gateway, and DNS servers to use in Step
3: Configure the instrument's LAN settings (on page A-7).
▪ Are blank: In the IP address field, enter 192.168.1.100. In the subnet mask field, enter
255.255.255.0. These will be used to configure the LAN settings of the instrument.
10. Click OK to close the Internet Protocol Version 4 (TCP/IPv4) Properties dialog box.
11. Click OK to close the Local Area Connection Properties dialog box.
12. Close the Network Connections window.
Windows 7: To disable DHCP:
1. Click Start > Control Panel.
2. Open Network and Sharing Center.
3. Click the Local Area Connection. The Local Area Connection Status dialog box is displayed.

Keithley 3706A Specifications

General

Model	3706A
Category	System Switch/Multimeter
Voltage Range	100 nV to 300 V
Basic DC Voltage Accuracy	0.0035%
Basic Resistance Accuracy	0.01%
Maximum Channels	576
Maximum Voltage	300 V
Connectivity	LAN, USB, GPIB
Interface	LAN, USB, GPIB
Switching Matrix	Yes
Channels	576 (6-slot mainframe)
Maximum Current	3 A
