Lubrication and Maintenance

KM00321,000031F -19-16JUN10-1/1

KM00321,000019E -19-05JUL12-1/1

Every 50 Hours - Hinges of Outer Sections

(390

plus

)

Lubricate with grease.

KM1000989 —UN—27AUG09

Every 50 Hours - Hinges of Outer Sections

(360

plus

, 375

plus

and 345

plus

)

Lubricate with grease.

ZX013901 —UN—26NOV97

50-10

031519

PN=104
