Attaching to a FENDT Forage Harvester
KM00321,0000129 -19-29MAR12-2/3
KM00321,0000129 -19-29MAR12-3/3
Continued on next page KM00321,000012D -19-29MAR12-1/2
2. Slide the guard over the joint until it engages.
KM1002263 —UN—29MAR12
3. Press sliding pin (A) and slide the joint onto the
splined shaft on the forage harvester until sliding pin
(A) engages in the ring-shaped groove.
A—Sliding Pin
KM1002253 —UN—29MAR12
Change the Hydraulic System
Move ball cock (A) to position for the relevant header.
KM1002264 —UN—29MAR12
23-4
031519
PN=66
