Kemper 345plus - Cleaning Rotary Harvesting Unit

Service
KM00321,000014A -19-26MAR09-1/1
Cleaning Rotary Harvesting Unit
Remove loose crop by means of compressed air and/or a
hand brush.
When using high pressure/steam cleaners, keep a
minimum distance (X) of 250 mm (9.84 in.). Refer
to specifications for the maximum temperature and
maximum pressure.
Specification
High pressure/steam
cleaner—Max.
temperature....................................................................... 50 °C (122 °F)
High pressure/steam
cleaner—Max. pressure............................... 8000 kPa (80 bar; 1160 psi)
KM1000798 —UN—09MAR09
X—250 mm (9.84 in.)
55-10
031519
PN=117
