Haulage
KM00321,0000201 -19-14AUG09-1/1
Transport Pallet
KM1000961 —UN—10JUL17
A—Transport pallet
Whenever the rotary harvesting unit is hauled separately
on a flatbed carrier, always fit the transport pallet (A)
supplied!
After the transport pallet (A) is fitted, the rotary harvesting
unit can be loaded with a fork lift.
CAUTION: Make sure that fork lift meets the
weight requirements of the rotary harvesting
unit (see Specifications Section.)
15-1
031519
PN=23
