X5 FastMig
Operating manual - EN
Crater fill
ON/OFF
Default = OFF
When welding with high power, a crater is
usually formed at the end of the weld. The
Craterfill function decreases the welding
power/ wirefeed speed at the end of the
welding job so that the cratercan befilled
using a lowerpowerlevel. TheCraterfill
level, voltage and time (only in 2T trigger
mode) are preset by the user.
- Crater fill time
Min/Max = 0.1 ... 5 s, step 0.1 s
Default = 1.0 s
- Crater fill wire feed speed
Min/Max = 0.5 ... 25 m/min
Step: 0.05 (if wirefeed speed < 5 m/min),
0.1 (if wirefeed speed >= 5 m/min)
Default: 5 m/min
- Crater fill voltage
Min/Max = 8 ... 60 V, step 0.1 V
Default = 18 V
WF end step
ON/OFF
Default = OFF
Wirefeed end step. This featureprevents
the filler wirefrom sticking to thework
piece when the welding ends. This is
accomplished by pulling thewireback
briefly.
Dynamics
Min/Max = -10.0 ... +10.0, step 0.2
Default = 0
Controls theshort circuit behavior of the
arc. The lower the valuethesofter the arc,
the higherthe valuetherougherthe arc.
Start arc length
-30 ... +30, step 1
Default = 0
Start arc settings affect the arc length and
duration at the ignition start.
Start arc time
-30 ... +30, step 1
Default = 0
Post current
-30 ... +30, step 1
Default = 0
Post current setting affects the wirelength
at the weld end. This also enables the
optimum wirelength for the start of the
next weld.
Wire feed speed min
Min/Max = 0.5 ... 25 m/min, step0.1
Default = 0.5 m/min
Minimumand maximum limits for the wire
feed speed adjustment.
Wire feed speed max
Min/Max = 0.5 ... 25 m/min, step0.1
Default = 25 m/min
Remote mode
OFF/Remote/Gun
Default = OFF
If remote controller is not connected, this
selection is not available.
Water cooler
OFF/Auto/ON
Default = OFF
Voltage display mode
Terminal voltage/ Arc voltage
Default = Arc voltage
Safe wire inch
ON/OFF
Default = OFF
When ON, and thearc doesn't ignite, the
filler wireis fed 5 cm. When OFF, 5 m of filler
wireis fed.
Cable calibration
Calibrate/Cancel The date and time and thecalibration
information of the previous calibration is
also shown.
Refer to
"Calibrating welding cable" on
page62
for cablecalibration.
MMA settings
The parameters listed here are available for adjustment with the MMA process.
Parameter Parameter value Description
