X8 MIG WELDER 2.8 Technical data
ValueFeature Description
500 A 500 A MV
Minimum short-circuit power S
SC
of
supply network
S
SC
5.1MVA 5.1MVA
Degree of protection IP23S IP23S
External dimensions LxWxH 921x348x795mm 921x348x795mm
Weight without accessories 95kg 95kg
Voltage supply for auxiliary devices U
aux
48V/500W 48V/500W
Voltage supply for cooling unit U
cu
- 220-230V±10%
380-460V±10% 380-460V±10%
Recommended generator power
(min)
S
gen
35kVA 35kVA
Wireless communication type
• Transmitter frequency and
power
2.4GHzWiFi &
Bluetooth
2.4 GHz Bluetooth
and WLAN
• 2400-2483.5
MHz 20 dBm
2.4GHzWiFi &
Bluetooth
2.4 GHz
Bluetooth and
WLAN
• 2400-2483.5
MHz 20 dBm
Wired communication type Ethernet & USB Ethernet & USB
Standards IEC 60974-1,-10 IEC 60974-1,-10
2.8.3 X8 Cooler
Feature Description Value
Operating voltage, U
1
3~50/60 Hz 220-230V±10 %
380-460V±10 %
Supply current (maximum) I
1max
1.0A
Supply current (effective) I
1eff
0.6A
Rated cooling power at 1 l/min 1.4kW
Rated cooling power at 1.6 l/min 1.9kW
Recommended coolant MPG4456 (Kemppi mixture)
Coolant pressure (max) 0.4MPa
Tank volume 4l
Operating temperature range * -10…+40°C
OPERATING MANUAL | EN 166
©
KEMPPI 2017 | 1817
