X8 MIG WELDER 2.4 Installation
2.4.6 Welding gun installation
Connect the welding gun to the wire feeder, prepare it for use, and change consumable parts.
2.4.6.1 Preparing and connecting welding gun
The X8 MIG Gun has been preassembled by the manufacturer: the wire liner, contact tip and gas
nozzle are premounted. To start using the gun, proceed as follows:
1.
Check that the wire liner, contact tip, gas nozzle are suitable for the job. Change if needed. If
your setup includes a gas-cooled gun, you can also change the neck.
2.
Attach the pistol grip handle, if suitable for the job.
3.
Attach X8 Gun Remote Control, if suitable for the job (optional, later release).
4.
Connect the welding gun to the wire feeder: Push the welding gun connector into the wire
feeder gun adapter, and hand-tighten the collar.
OPERATING MANUAL | EN 60
©
KEMPPI 2017 | 1817
