X8 MIG WELDER 2.4 Installation
Note:
X8 MIG Guns connect to X8 Wire Feeder with a special Kemppi Gun Adapter that
enables, among other things, accurate measurement of the actual arc voltage and
the usage of the remote control (available in a later release). Therefore, X8 MIG Guns
are only compatible with X8 Wire Feeder.
5.
If your setup includes a water-cooled gun, connect the cooling hoses to the wire feeder. The
coolant inlet hose is marked with blue and the coolant outlet hose with red.
6.
Dress the sharp filler wire tip before loading to improve wire loading and consumables life.
7.
Load the filler wire by pressing the Wire inch button.
OPERATING MANUAL | EN 61
©
KEMPPI 2017 | 1817
