X8 MIG WELDER 2.3 System structure
The parts of X8 MIG Welder are in close co-operation with each other. The information transfer is
efficient and quick, and the different functions, for example, the use of displays, follow the same
principles.
Caution:
Do not modify the welding equipment in any way, except for the changes and
adjustments covered in the manufacturer’s instructions.
Figure 1: A chart of the connections between the different parts of X8 MIG Welder
2.3.1 X8 Power Source
This section describes the X8 Power Source structure.
