X8 MIG WELDER 2.3 System structure
Control panel
The control panel on the front of the wire feeder enables easy control of the wire feeder's basic
features. Although Control Pad is the main control of the welding system, you can also use the
wire feeder control panel or the welding gun remote control.
5
6
2
1
4
3
5
6
2
1
4
3
The wire feeder control panel parts are:
1. Locking button
Press and hold for 2 seconds to lock or release the display and buttons.
2. Channel button
The button lights up blue, when the view is activated.
OPERATING MANUAL | EN 18
©
KEMPPI 2017 | 1817
