Kemppi X8 User Manual

X8 MIG WELDER 2.8 Technical data
Feature Description Value
Coolant flow rate 1l/min
Coolant pressure (max) 5bar
Type of connection Kemppi
Wire diameters 0.8/0.9/1.0/1.2/1.6mm
@60% (MIXED
GAS)
@100% (MIXED
GAS)
400A
@60% (CO
2
)
Load capacity
@100% (CO
2
)
Fe 0.8/0.9/1.0/1.2/1.6mm
Fe-MC/FC 0.9/1.0/1.2/1.6mm
Ss 0.8/0.9/1.0/1.2/1.6mm
Ss-MC/FC 0.9/1.0/1.2/1.6mm
Filler wires
Al 0.8/0.9/1.0/1.2mm
Operating temperature range -20…+40°C
Storage temperature range -40…+60°C
Minimum cooling power at 1.6l/min*
1.9 kW
Minimum flow rate 1.6 l/min
Pistol grip handle Yes
Changeable neck No
Rotating neck No
Length x (see
figure below)
131mmNeck dimensions
Height y (see
figure below)
105mm
Neck angle ɑ (see figure
below)
50°
Standards IEC 60974-7
*Gun length 5 m
OPERATING MANUAL | EN 173
©
KEMPPI 2017 | 1817
