X8 MIG WELDER 2.4 Installation
Note:
The mounting pins are different: The drive rolls' mounting pins have a circular mark
on the top, while the pressure rolls' mounting pins have no marks. The pressure rolls'
mounting pins have central axles attached to them, so the drive and pressure rolls'
mounting pins cannot be confused with each other.
3.
Pull the drive rolls upwards (1) and the pressure rolls out of their slots (2).
