X8 MIG WELDER 2.4 Installation
Changing liner (gas-cooled gun)
1.
Lay the welding gun cable straight on a flat surface.
2.
Loosen the neck tightener by rotating it half a turn, and remove the neck.
3.
Remove the guide nut from the tip of the sleeve.
4.
Remove the sleeve and pull out the liner. Make sure the cone and the seal slide out with the
liner.
OPERATING MANUAL | EN 75
©
KEMPPI 2017 | 1817
