Kemppi X8 - Page 85

X8 MIG WELDER 2.4 Installation
6.
Cut the excessive liner (spiral liner with side cutting pliers, DL Chili liner with a carpet knife)
leaving 1 - 2 mm.
1-2 mm
7.
Attach the guide nut at the tip of the sleeve.
OPERATING MANUAL | EN 85
©
KEMPPI 2017 | 1817
