2. Safety
Suppliers of articles for use at work are required under section 6 of the Health and Safety at Work act 1974 to ensure as reasonably
as is practical that the article will be safe and without risk to health when properly used.
An article is not regarded as properly used if it is used ‘without regard to any relevant information or advice’ relating to its use made
available by the supplier.
This product should be installed, commissioned and maintained by trained service personnel in accordance with the following:
(i) IEE regulations for electrical equipment in buildings
(ii) Codes of practice
(iii) Statutory requirements
(iv) Any instructions specifically advised by the manufacturer
According to the provisions of the Act you are therefore requested to take such steps as are necessary to ensure that you make any
appropriate information about this product available to anyone concerned with its use
This equipment is designed to operate from 230V 50Hz mains supplies and is of class 1 construction. As such it must be connected
to a protective earthing conductor in the fixed wiring of the installation. A readily accessible double pole disconnect device with a
disconnect air gap of at least 3mm and conforming to EN 60950, shall be incorporated in the fixed wiring.
Failure to ensure that all conductive accessible parts of this equipment are adequately bonded to the protective earth
will render the equipment unsafe.
3. Technical specification
Overall size 385mm x 310mm x 90mm
Finish BS 00 A 05 mid grey fine texture
Mains supply 230V AC, 50Hz +10% -15% (100 Watts maximum)
Mains supply fuse 1.6Amp (F1.6A L250V)
Power supply rating Imax a 400 milliamps
Power supply rating Imax b 2.3 Amps
Operating voltage 18 to 30 volts DC
Battery charging circuit impedance Rimax 1.35R
Minimum output current for correct operation Imin 130 milliamps
Maximum ripple voltage 1.5+/- 0.3 Volts
Battery type Yuasa NP 7Ah Flame retardant UL94:V-0
Battery charge voltage 27.6V DC nominal (temperature compensated)
Battery charge current 0.7A
Battery fuse 20mm 3.15A glass
Maximum current draw from batteries 3 Amps
Aux 24V output rating 300 milliamps maximum load (fused at 500 milliamps)
Sounder output rating (two outputs) Each rated at 1A
Relay contacts 30V DC, 1 Amp maximum
Detection loop current 400 milliamps maximum
