Applicable SCMs
The following are the SCMs that can be used with the transceiver:
Table 3-3 Available SCMs
SCM Firmware Version
KWD-AE30 A3.0.3
KWD-AE31 A3.0.3
KWD-DE31 D4.0.3
Note
0
The Encryption function using AES/ DES is unavailable if an SCM having firmware version earlier than the versions
described above is installed in the transceiver.
0
Information
(such as the model name and the firmware version of the SCM installed in the transceiver) can be viewed in
the Transceiver Information dialog box using KPG-D1/ D1N.
Installing KWD-AE30/ KWD-AE31
Refer to the Installation Manual or the service manual supplied with KWD-AE30/ KWD-AE31 for instructions on how to install
KWD-AE30/ KWD-AE31 in the transceiver.
Key Loader
Using the Key Variable Loader or the Software Key Loader, Encryption Key data can be configured on the SCM and
configured Encryption Key data can be deleted.
Key Variable Loader
An Encryption Key can be configured on the SCM by using the Motorola KVL 3000/ KVL 3000 Plus/ KVL 4000.
“KEYLOAD” appears on the display and the transceiver enters the KVL mode, after connecting KVL 3000/ KVL 3000Plus/
KVL 4000 to the transceiver with the connection cable and turning ON the transceiver.
Alternatively, “KEYLOAD” appears on the display and the transceiver enters the KVL mode, after connecting KVL 3000/
KVL
3000Plus/ KVL 4000 to the transceiver with the connection cable and turning ON the transceiver with the [H] key being
pressed. The operations available using KVL 3000/ KVL 3000Plus/ KVL 4000 are as follows:
0
Key Load
An Encryption Key can be configured on the SCM.
0
Key Delete
The Encryption Key configured on the SCM can be deleted.
0
Key View
A Key ID, CKR and Algorithm ID configured in the transceiver can be displayed.
3 COMMUNICATION SECURITY
3.4 Secure Cryptographic Module (SCM) (for AES/ DES Only)
DMR FUNC (K, F)/Ver 2.20 124
