Control Tone
Tone Name
Pattern
Reference
Key Beep A
1 beep
1630 Hz
(50 ms)
Broadcast Group Call
Lone Worker
Activity Detection
Single Scan
List Scan
Multi-Zone Scan
Scan Program
Priority Scan
Key Beep B
2 beeps
1630 Hz
(50 ms)
Lone Worker
Activity Detection
Single Scan
List Scan
Multi-Zone Scan
Scan Program
Priority Scan
Key Beep C
3 beeps
1630 Hz
(50 ms)
Priority Scan
Key-entry Error Tone
1 beep
700 Hz
(50 ms)
Scan Delete/Add
Priority-channel Tone
1 beep
2000 Hz
(50 ms)
Priority Scan
Priority-channel Stop Tone
Scan Stop Tone
2 beeps
700 Hz
(50 ms)
Channel Recall
Scan Stop Tone
Search Mode Tone
1 beep
770 Hz
(400 ms)
DMR Site Roaming
Call Request Tone
1 beep
1630 Hz
(50 ms)
Individual Call Acknowledge Request
Call Request Tone
7
BEEP
LIST
7
BEEP LIST
