The following is the difference in operation for transmission depending on the transceiver configuration and the received
signal.
Table 1-7 Mixed Mode 2
Optional
Signaling
Transmit
Mode
Received
signal
Transmission Operation
Disabled Analog Digital
The transceiver can transmit using the Color Code preconfigured for the transceiver
until the length of time configured in Signaling Reset Timer elapses.
Disabled Analog Analog
The transceiver can transmit using the QT tone or DQT code preconfigured for the
transceiver until the length of time configured in Signaling Reset Timer elapses.
Disabled DMR Digital
The transceiver can transmit using the Color Code preconfigured for the transceiver
until the length of time configured in Signaling Reset Timer elapses.
Disabled DMR Analog
The transceiver can transmit using the QT tone or DQT code preconfigured for the
transceiver until the length of time configured in Signaling Reset Timer elapses.
Enabled Analog Digital
The transceiver can transmit using the Color Code preconfigured for the transceiver
and specifying the received ID until the length of time configured in Auto Reset
Timer elapses.
Enabled Analog Analog
By specifying the received ID, the transceiver can transmit using the QT tone or DQT
code preconfigured for the transceiver until the length of time configured in Auto
Reset Timer elapses.
However, ID can be specified only when FleetSync signaling is received. The
transceiver can transmit using only QT tone or DQT code preconfigured for the
transceiver if the transceiver receives a DTMF or 2-tone code, or an MDC-1200 ID.
Enabled DMR Digital
The transceiver can transmit using the Color Code preconfigured for the transceiver
and specifying the received ID until the length of time configured in Auto Reset
Timer elapses.
Enabled DMR Analog
By specifying the received ID, the transceiver can transmit using the QT tone or DQT
code preconfigured for the transceiver until the length of time configured in Auto
Reset Timer elapses.
However, ID can be specified only when FleetSync signaling is received. The
transceiver can transmit using only QT tone or DQT code preconfigured for the
transceiver if the transceiver receives a DTMF or 2-tone code, or an MDC-1200 ID.
Note
0
While the transceiver is in Emergency Mode, the transceiver transmits according to the configuration in Transmit
Mode.
0
If
the transceiver receives FleetSync data, the transceiver sends an ACK in analog mode, and if the transceiver receives
DMR data, the transceiver sends an ACK in digital mode. The transceiver transmits according to the configuration in
Transmit Mode after the transceiver ends data communications regardless of the configuration in Signaling Reset
Timer or Auto Reset Timer.
0
If “Off” is configured in Signaling Reset Timer, the transceiver retains the status of transmission in the same mode as
that of the received signal. This status will be reset by an operation such as changing a channel.
0
If “0” is configured in Signaling Reset Timer, the transceiver transmits according to the configuration in Transmit
Mode.
Configuration using KPG-D1/ D1N
0
Configuring Channel Type
and Transmit Mode (Personality) (
Transceiver
Settings > Personal > Personality >
DMR Conventional > General)
0
Configuring Channel Type and Transmit Mode (Channel Edit) (
Transceiver
Settings > Zone/Channel > Channel
Edit > DMR Conventional > General)
0
Configuring Signaling Reset Timer (
Transceiver Settings > DMR > DMR Information > General)
1 DMR CONVENTIONAL SYSTEM
1.3 Waiting for Both Digital Signals and Analog Signals (Mixed Mode)
DMR FUNC (K, F)/Ver 2.20 14
