Kenwood NX-5200K3 Function Reference

2
Receive an acknowledgment message from the receiving transceiver.
The “ ” icon blinks, and the transceiver enters a state allowing
transmission of an Individual Call.
Receiving an acknowledgment message while the PTT switch is being
pressed initiates an Individual Call.
3
Press the PTT switch.
The Individual Call is initiated.
Menu Zone +
Individual
TRUCK 824
12 : 34
A
M
Note
0
If the Call Request Tone is
enabled, a Call Request Tone (1 beep) sounds from the transceiver when a call request for
an Individual Call (Individual Call Acknowledge Request) is initiated. Also, if the Call Processing Tone is enabled, a Call
Processing Tone (2 beeps) sounds from the transceiver until the transceiver receives an acknowledgment message from
the receiving transceiver after the call request for an Individual Call (Individual Call Acknowledge Request) is sent. (Refer
to Notifying the User with a Tone That a Call Request Has Been Initiated (Call Request Tone), Notifying the User with a
Tone That a Call Request Is in Progress (Call Processing Tone).)
0
If Call in Progress Tone is enabled, a Call in Progress Tone (2 beeps) sounds from the transceiver when the transceiver
becomes ready for transmissions with Individual Call.
0
If PTT Proceed Tone is enabled, a Proceed Tone (3 beeps) sounds from the transceiver when the transceiver becomes
ready for communications after the PTT switch is pressed. (Refer to Common FUNC Using Sound to Notify the Timing
to Start Communications (PTT Proceed Tone).)
0
While the transceiver is on standby to receive an acknowledgment message from the receiving transceiver, canceling
the call is possible by pressing the Clear key.
0
The transmitting transceiver sends a message requesting another acknowledgment when the length of time configured
in Maximum ACK Wait Time elapses without receiving an automatic response message for a message requesting an
acknowledgment from the receiving transceiver. If a response message cannot be received, the transmitting transceiver
can send a message requesting an acknowledgment up to the number of times configured for Number of Retries. (Refer
to Maximum ACK Wait Time, Number of Retries.)
0
The transceiver terminates the call if the transceiver cannot receive an automatic response message from the receiving
transceiver even if a message requesting an acknowledgment has been sent for the number of times configured in
Number of Retries. At that time, “No Reply” appears on the display for 1 sec. (Refer to Number of Retries.)
Configuration using KPG-D1/ D1N
0
Assigning functions to the PF
keys on the transceiver (
Transceiver Settings > Key Assignment)
0
Assigning functions to the AUX Input port ( Transceiver Settings > Extended Function > AUX)
0
Configuring Selcall
on PTT (
Transceiver Settings > Personal > Personality > DMR Conventional > DMR > Selcall
on PTT)
0
Configuring Selcall on PTT (Channel Edit) ( Transceiver Settings > Zone/Channel > Channel Edit > DMR
Conventional > DMR > Selcall on PTT)
0
Configuring
the Unit ID corresponding to the Call 1 to Call 6 key or port (
Transceiver Settings > Key Assignment
> Call)
1 DMR CONVENTIONAL SYSTEM
1.6 Initiating an Individual Call After Ensuring That the Target Party Is Available for Communications (Individual Call Acknowledge Request)
DMR FUNC (K, F)/Ver 2.20 27
