Sending GPS Data According to the Request from the Base Station (GPS Report
Mode)
GPS Report Mode
allows the transceiver to automatically send GPS data when a GPS data transmission request is received
from the base station.
This function is used when the base station controls the timing to require GPS data. This function is also used to avoid a
data collision if there are many transceivers.
To use this function, “Poll” must be configured for GPS Report Mode by using KPG-D1/ D1N.
Note
The transceiver sends GPS data to the ID configured for GPS Base ID or Base ID, not to the ID that sent the data
transmission request. However, if GPS Report Back to Requested ID is enabled, GPS data is sent to the ID that sent
the data transmission request. (Refer to GPS Report Back to Requested ID.)
Configuration using KPG-D1/ D1N
Configuring GPS
Report Mode (
Transceiver Settings > Personal > Personal Features > DMR Conventional > GPS)
Sending GPS Data Manually by Using a Key (Send the GPS Data)
GPS data can be sent manually by a user pressing the Send the GPS Data key. Or, pressing the Menu key causes the
transceiver
to enter Menu Mode, and then the GPS data can be sent manually by selecting the “Send the GPS Data”. (Refer
to Common FUNC Using Menu Mode.)
Configuration using KPG-D1/ D1N
Assigning functions to the PF
keys on the transceiver (
Transceiver Settings > Key Assignment)
Sending GPS Data Based On Travel Distance (GPS Distance Change)
GPS Distance Change allows the transceiver to send GPS data when the distance between the location of the previous
GPS data transmission and the current location exceeds the value configured in Distance Value.
The transceiver calculates the distance between the position where the GPS data was sent and the current position at
regular time intervals (3 sec) after the transceiver automatically or manually sent GPS data. The GPS data is sent if the
calculated
distance exceeds the value configured for Distance Value. If no GPS data is sent after the transceiver is turned
on, the transceiver regards the location information first received from the GPS unit as the previous transmission position
and calculates the distance to the current position. The distance is calculated from the latitudinal and longitudinal values.
Configuration using KPG-D1/ D1N
0
Configuring GPS Distance Change to be enabled or disabled (
Transceiver Settings > Personal > Personal
Features > DMR Conventional > GPS > GPS Distance Change)
0
Configuring Distance
Value (
Transceiver Settings > Personal > Personal Features > DMR Conventional > GPS
> GPS Distance Change)
1 DMR CONVENTIONAL SYSTEM
1.15 Sending GPS Data
DMR FUNC (K, F)/Ver 2.20 67
