Keysight Technologies 33210A - Page 109

Block Diagram 5
Keysight 33210A Service Guide 109
The output is protected by a relay. When the relay is open, the instrument can read the value of the Main Output Circuit. The output relay is opened on user command, if a current overload is detected, or if a voltage over–range condition is found.
