+10 dB Range Flatness Verification
This procedure checks the high frequency ac amplitude flatness above 100 kHz on
the +10dB attenuator range. (Flatness is relative to 1 kHz.)
1 Connect the power meter to measure the output amplitude of the instrument
as shown on page 72.
2 Set up the function generator as follows:
– Output impedance: 50 Ω (press and select Output Setup).
–Waveform: Sine
– Frequency: 100 kHz
– Amplitude: 13.00 dBm
Make sure the output is enabled.
3 On the power meter, use the Relative Power function to set the current reading
as the reference value. This will allow you to compare future measurement
results in dB.
4 Set the power meter offset to equal the 100kHz_10dB_offset value previously
calculated. This sets the power meter to directly read the flatness error
specification relative to 1 kHz. 100kHz_10dB_offset is calculated on the
"Amplitude and Flatness Verification Worksheet".
5 Set the instrument to each output described in the table below and measure
the output amplitude with the power meter (the relative measurement in dB).
Keysight 33210A Measurement
Output Setup Function Amplitude Frequency Nominal Error
Q 50 Ω Sine Wave +13.00 dBm 100.000 kHz 0 dB ± 0.1 dB
50 Ω Sine Wave +13.00 dBm 200.000 kHz 0 dB ± 0.2 dB
50 Ω Sine Wave +13.00 dBm 500.000 kHz 0 dB ± 0.2 dB
50 Ω Sine Wave +13.00 dBm 2.000 MHz 0 dB ± 0.2 dB
50 Ω Sine Wave +13.00 dBm 3.000 MHz 0 dB ± 0.2 dB
Q 50 Ω Sine Wave +13.00 dBm 4.000 MHz 0 dB ± 0.2 dB
50 Ω Sine Wave +13.00 dBm 5.000 MHz 0 dB ± 0.2 dB
